• WEBENCH® CAD/CAE Symbols

    • Step 1: - Before installing a new version of UltraLibrarian software ZIP: 77MB you must

    Ensure that you have uninstalled all previous versions of UltraLibrarian on your local machine.

    Delete previous versions of UltraLibrarian directory (C:\UltraLibrarian) completely on your local machine.

    Download and run the executable in Administrator mode and install the UltraLi brarian software in c:/UltraLibrarian on your local machine.

    Step 2: - Click on the desired part below and OPEN the file to start Ultra Librarian.

    Step 3: - Follow the instructions in Ultra Librarian.


    Click Links Below To Download Files
    SYMBOL(BXL)STEP(3D CAD)PDF(3D VIEW)IMAGE
    DS90UB681-Q1_RTD_64.bxl.........
    DS90UB901Q-Q1_RTV_32.bxlRTV0032A.stpRTV0032A_3D.pdf
    DS90UB902Q-Q1_RTA_40.bxlRTA0040A.stpRTA0040A_3D.pdf
    DS90UB903Q-Q1_RTA_40.bxlRTA0040A.stpRTA0040A_3D.pdf
    DS90UB904Q-Q1_RHS_48.bxlRHS0048A.stpRHS0048A_3D.pdf
    DS90UB925Q-Q1_RHS_48.bxlRHS0048A.stpRHS0048A_3D.pdf
    DS90UB933-Q1_RTV_32.bxlRTV0032A.stpRTV0032A_3D.pdf
    DS90UB934-Q1_RGZ_48.bxlRGZ0048B.stpRGZ0048B_3D.pdf
    DS90UB940-Q1_NKD_64.bxlNKD0064A.stpNKD0064A_3D.pdf
    DS90UB948-Q1_NKD_64.bxlNKD0064A.stpNKD0064A_3D.pdf
    DS90UB949-Q1_RGC_64.bxlRGC0064K.stp...
    DS90UB954-Q1_RGZ_48.bxlRGZ0048B.stpRGZ0048B_3D.pdf
    DS90UB960-Q1_RTD_64.bxlRTD0064F.stpRTD0064F_3D.pdf
    DS90UB964-Q1_RGC_64.bxlRGC0064K.stp...
    DS90UB9702-Q1_RUR_88.bxlRUR0088E.stpRUR0088E_3D.pdf
    DS90UB971-Q1_RHB_32.bxlRHB0032U.stpRHB0032U_3D.pdf
    DS90UB9722-Q1_RUR_88.bxlRUR0088E.stpRUR0088E_3D.pdf
    DS90UB981-Q1_RTD_64.bxlRTD0064M.stpRTD0064M_3D.pdf
    DS90UB984-Q1_RUR_88.bxlRUR0088D.stpRUR0088D_3D.pdf
    DS90UB988-Q1_RUR_88.bxlRUR0088D.stpRUR0088D_3D.pdf


    Each .bxl file contains both a schematic symbol and at least one footprint (exception for custom formed lead devices which have no footprint). The .stp file, if available, contains a 3D STEP model. With the exception of DSBGA, QFN, and SON packages which only have one footprint, the footprints in the .bxl are available in three sizes per the IPC-7351 standard for the least, nominal, and most real estate on the PCB. The naming convention for the files is as follows:

    Name Description
    xxxxxx Nominal footprint (nominal packing density)
    xxxxxx-L Least footprint (highest packing density)
    xxxxxx-M Maximum footprint (lowest packing density)

    For more information on the IPC-7351 standard visit IPC Review
    For more information on Cad Tools visit CAD/CAE Symbols

    Provided by Accelerated Designs Inc. & the Ultra Librarian

    Please enter at least the first 4 characters of Texas Instruments' part number.
    Only one part number at a time.
